MARCOTTE
MANCORE900H

Our portable solution for deep drilling in restricted areas

  • 8 modules for a total of 11,300 lbf
  • Accommodate 20 ft rod strings
  • Light construction
  • Equipped with Rexroth components

The MARCOTTE Mancore 900H modular Drill Rig can be dismantled and transported to remote drilling locations.

The MARCOTTE Mancore 900H is the most versatile exploration drill you can get. With its wide range of options and high capacity, it will always be ready to take on the most diverse and challenging jobs that you will encounter in mining exploration.

CAPACITY

Engine

Pull

Torque

Mast angle

DEPTH RANGES

on BWL

on NWL

on HWL

Drilling Unit

5.5 ft

Average feed cylinder speed

2.42 ft/sec

Average feed cylinder speed

4 speeds

Funk transmission

Hoist Wireline

3,500 ft

Storage capacity

2,200 lb max.

Pull capacity

950 ft/min max.

Speed capacity

Power Unit

45 USgal

Fuel tank

33 USgal

Hydraulic tank

Water/Oil

Heat exchange unit

OPTIONS
  • Lightweight hydraulic manipulator for on-the-fly work
  • Auxiliary hydraulic pump for extra 20 gpm at 3000 psi
  • Multiple foot clamps compatible with the mast
  • Casing clamp below the foot clamp
  • Skid frame with tow bar for on-the-fly work
  • Removable composite panel shack for weather protection
  • Can be supplied with biodegradable oil
  • Air/oil heat exchanger
  • Water pump and tank
  • Mud mixer
  • Custom safety features as required by customer
  • Heavy shack on skid (non-fly)
  • Standard hydraulic rod handler for heavy shack
ACCESSORIES
  • Drill head torque control
  • Clamp and chuck synchronization
  • Screw and unscrew function
  • 32 hp of hydraulic power available for water pump

Download our specification sheet for our MARCOTTE MANCORE 900H Drill Rig.
